cue:scale — Scaling Animation

scale() adjusts the size of SVG objects using sequences, patterns, continuous pulsing, or independent X/Y scaling.

BASIC FORMS

To a size, and stay

scale(1.5)            at once
scale(0.5, dur:2)     gliding there over 2 beats, from the size it has
scale(2, 0.5)         width and height

From the live console: s3 > scale(1.5). A scale with a rotate on the same shape: they compose.

Uniform scaling

scale(values:[1,1.5,1], dur:2)

Non-uniform (XY)

scaleXY([1,1.3],[1,0.6], dur:1)
scale(x:[1,1.3], y:[1,0.6], dur:1)
scaleXY(Prand([0.5,1.5],inf), Prand([0.5,1.5],inf), dur:0.3, interp:step)

The first list (or pattern) is the width, the second the height; each steps on its own.

Continuous pulse

scale(min:1, max:1.3, dur:2)

TRIGGERING

• automatic page-mode
• scroll edge
• cue activation

TRIGGER DELAY

tdelay:<beats>

Delays scaling start.

scale(values:[1,1.4,1], tdelay:3)

INITIAL VISIBILITY

init:

Controls how the element appears before the animation begins.

Initial scale is applied immediately regardless of init state.

scale([1,1.5,1], tdelay:4, init:ghost)
scale([1,2,1], dur:3, init:fadein(1))
scale([1,1.4,1], dur:2, init:armed)
scale([1,1.4,1], dur:2, init:armed(0.3), trig:playhead)

SEQUENCES

Pattern forms (Pseq, Prand, etc.) supported for all parameters.

CONTINUOUS SCALING

scale(min:1, max:1.4, dur:1.5, loop:0)

UID — Live Updates

scale(values:[1,1.2,1], uid:s1)
scale(uid:s1, dur:0.5)

NETWORK SYNCHRONIZATION

By default, scale animations are synchronized across all connected clients. The first client to start an animation becomes the leader and broadcasts positions every 10 seconds. Late-joining clients sync to the leader's position.

sync: — Enable/Disable Sync

Use sync:0 for animations that should vary between performers:

scale(values:[1,1.5,1], dur:2, sync:0)

SIGNAL-BOUND PARAMETERS

Animation speed, duration, and scale values can be controlled in real-time by binding to fader signals from the control plane.

Signal Reference Syntax

scale(min:1, max: follow(scaleFader.t, 1, 2), dur: follow(speedFader.t, 4, 0.5), uid:pulse)

The signal reference format is:

follow(source.channel, min, max[, default][, curve])

Examples

// Duration controlled by fader: 4 beats (slow) to 0.5 beats (fast)
scale(min:1, max:1.5, dur: follow(speedFader.t, 4, 0.5), uid:pulse)

// Scale max controlled by fader: 1x to 2x
scale(min:1, max: follow(sizeFader.t, 1, 2), dur:1, uid:growPulse)

// Independent X/Y scale bound to different faders
scaleXY(sx: follow(xFader.t, 1, 2), sy: follow(yFader.t, 1, 1.5), dur:2, uid:xyScale)

// With exponential curve for finer control
scale(min:1, max:1.5, dur: follow(speedFader.t, 4, 0.5, exp3), uid:smoothPulse)

How It Works

1. The fader publishes its position (0-1) to the control plane
2. The value is mapped through the specified range and curve
3. The animation's parameter updates in real-time

See Control Plane documentation for full signal reference syntax.

FULL PARAMETER LIST

EXAMPLES

scale([1,2,1], dur:2, tdelay:3)
scaleXY([1,1.4],[1,0.6], dur:1)
scale(Pseq([1,1.5,1],inf), dur:Prand([0.5,1],inf))

Stopping: off:1

scale(off:1) on the same element stops it at the size it has reached. Run the scale again to start it from there. In the live console Ctrl+Shift+. on the line does this.

What a scale publishes

uniform is the one to reach for when a shape scales evenly and you want one number out of it rather than picking sx arbitrarily.

follow(name.channel, lo, hi) reads its channel as 0..1, and the factors are not: uniform going 0.1 → 3 would send a 200..4000 range up to 11 600. t is already 0..1 across the scale's own range, so it sweeps exactly lo to hi:

synth(uid:bass, wave:saw, filter:{type:lp, freq:follow(bsc.t, 200, 4000), q:1})
bass > scale(uid:bsc, values:[0.1, 3], dur:1)

Give the scale a uid: to follow it by: without one it is named at random.

A scale can follow a signal too. Its size follows, as its sizes are given otherwise -- first, or as values: -- both axes at once; sx: and sy: follow one axis each (a lone sx: stretches the width only):

bass > scale(follow(bass.t, 0.2, 1.5))                  the synth's pitch sets the size
bass > scale(follow(bass.t, 0.2, 1.5), uid:bsc)         ... named, to follow in turn
bass > scale(uid:bsc, values:follow(bass.t, 0.2, 1.5))  the same
bass > scale(sx:follow(bass.t, 1, 3))                   only wider

Following, it publishes t as well: where it is in the follow() range.

scale(uid:pulse, values:[1, 1.8, 1], dur:2, loop:0)
rotate(uid:r1, dir:1, dur: follow(pulse.uniform, 6, 0.5))

sx, sy and dur are also inlets — see the connections view.

Demo

See demo-scale — uniform and per-axis scaling, value lists, and signal-bound sx/sy.

http://localhost:8001/?project=demo-scale
